25.6V 100Ah LiFePO4 Battery Pack with 100A Discharge

Brand Name : OiD

Model Number : OiD100Ah-25.6

Place of Origin : China

Certification : CE, UL, UN38.3

MOQ : 100pcs

Price : $0.5 ~ $100.0 / pcs

Delivery Time : 3 ~ 7 days for storage

Payment Terms : TT,L/C,Western Union

Name : 100Ah Lithium Battery Pack

ODM : Free custom design for packs

Battery Type : 25.6V 20Ah Rechargeable

Cathode : LiFePO4 (LFP)

Cycle Life : 2000+ cycles

Operating Temperature : -20°C~60°C

Safety : Support BMS

Charging/ Discharging : 50A/100A

Contact Now

OiD100Ah-25.6 25.6V 100Ah 100A Discharge 2000+ Cycles Battery Pack

Product Name

OiD100Ah-25.6 LiFePO4 Battery Pack

Advantages

High cycle life (>2000 cycles at 70% DOD)
Wide operating temperature range (-20°C to 60°C discharge)
IP65-rated rugged design for harsh environments
Built-in BMS with multi-layer protection
Supports parallel/series configurations (up to 4 units)

Specifications

Parameter	Details
Nominal Voltage	25.6V
Nominal Capacity	100Ah (min. 97Ah)
Energy	2560Wh
Terminal Type	M8 (corrosion-resistant)
Dimensions (L×W×H)	522×240×215/220 mm ±2mm (incl. terminals)
Weight	27.5kg ±5%
IP Rating	IP65
Max Charging Current	50A (0°C to 45°C)
Max Discharging Current	100A (-20°C to 60°C)
Discharge Termination Voltage	20V

Cycle Life

Test Condition	Performance
Cycle Count	>2000 cycles
Depth of Discharge (DOD)	70%
Temperature	25±5°C
Remaining Capacity at EOL	≥70% of initial capacity

Operating Temperature Range

Mode	Temperature Range
Charging	0°C to 45°C
Discharging	-20°C to 60°C
Storage (≤6 months)	≤35°C at 50% SOC
Storage (≤3 months)	≤45°C at 50% SOC

Key Features

BMS Protection: Over-voltage, over-current, over-temperature, and cell balancing.
High Discharge Capability: Sustains 100A continuous output.
Parallel/Series Ready: Voltage difference <0.1V for stable configurations.
Self-Discharge Control: ≤10% capacity loss after 28 days at 25°C.

BMS Specifications

Model: 8S100A
Functions:
- Over-voltage cutoff (14.6V max)
- Over-current protection (100A max)
- Temperature monitoring (-20°C to 60°C)
- Passive cell balancing

Applications

Solar energy storage systems
Uninterruptible Power Supplies (UPS)
Electric vehicles (e.g., golf carts, AGVs)
Off-grid power solutions
Telecom base stations
Marine and RV power systems

25.6V 100Ah LiFePO4 Battery Pack with 100A Discharge

Usage Warnings & Precautions

Avoid short circuits, water immersion, or physical impacts.
Do not charge below 0°C or above 45°C.
Use only compatible chargers; reverse polarity may damage the battery.
Prohibit installation in high-vibration, high-humidity, or direct sunlight areas without protective measures.
Replace immediately if leakage, swelling, or abnormal heating occurs.

Storage Guidelines

Store at ≤25°C (12 months) or ≤35°C (6 months) with 50% SOC.
Recharge every 3 months if stored at ≤45°C.
Keep in dry, ventilated environments away from heat sources.

Warranty & Disclaimer

Warranty: 24 months from shipment or until reaching 2000 cycles (whichever comes first).
Exclusions: Damage from misuse, improper storage, or operation beyond specified limits (e.g., over-temperature, over-current).
