OiD801752N750 3.7V 750mAh 1C Discharge 500 Cycles Pet Li-ion Battery

Brand Name : OiD

Model Number : OiD801752N750

Certification : Complies with GB/T 18287-2013, IEC/EN61960, and UL1642 safety standards.

Place of Origin : China

MOQ : 100pcs

Name : Lithium Ion Battery

Battery Type : 3.7V, 750mAh Rechargeable

ODM : Free custom design for packs

High Energy Density : 250-300Wh/kg

Cycle Life : 500+ cycles

Superior Cold Weather Performance : Reliable in Extreme Cold (-20°C to 60°C)

Charging/ Discharging : 1C/ 1C

Flexible Form Factor : Thin, Customizable Pouch Design Lithium Ion Battery

Price : $0.5 ~ $100.0 / pcs

Delivery Time : 3 ~ 7 days for storage

Payment Terms : TT, L/C, Western Union

Contact Now

Product Name

OiD801752N750 Rechargeable Li-ion Battery

Advantages

High energy density and lightweight design
Stable performance with built-in protection circuit
RoHS compliant and environmentally friendly

Specifications

Parameter	Value
Nominal Voltage	3.7V
Capacity (Typical/Min)	750mAh / 730mAh (0.2C discharge)
Charging Voltage	4.2V
Discharge Cut-off Voltage	3.0V
Standard Charging Current	0.2C
Max Charging Current	1.0C (20°C–45°C)
Standard Discharging Current	0.2C
Max Discharging Current	1.0C (25°C–60°C)
Impedance	≤180mΩ
Weight	Approx. 14.1g

Cycle Life

Condition	Performance
Charge/Discharge Cycles	500 cycles (0.2C, 23±2°C)
Capacity Retention	≥80% of initial capacity

Discharge Curve

Operating Temperature Range

Condition	Temperature Range	Current Limit
Charging	0°C to 45°C	0.2C (0°C–10°C)
		0.5C (10°C–20°C)
		1.0C (20°C–45°C)
Discharging	-20°C to 60°C	0.2C (-20°C–0°C)
		0.5C (0°C–25°C)
		1.0C (25°C–60°C)
Storage (50% SOC)	-10°C to 25°C (12 months, ≥85%)	N/A

Certifications

Complies with GB/T 18287-2013, IEC/EN61960, and UL1642 safety standards.

Key Features

Overcharge/over-discharge/short-circuit protection.
Low self-discharge rate for long shelf life.
Compact dimensions: Max 54.0mm (L) × 17.7mm (W) × 8.2mm (H).

Applications

Pet tracking devices and wearable tech.
Small medical devices and IoT sensors.
Portable consumer electronics.

OiD801752N750 3.7V 750mAh 1C Discharge 500 Cycles Pet Li-ion Battery

Usage Warnings & Precautions

Avoid short-circuiting terminals or exposing to water.
Do not disassemble, crush, or incinerate.
Stop use if swelling, leakage, or overheating occurs.

Storage Guidelines

Store at 20±5°C (recommended) with 50% SOC.
Recharge to 60% every 3 months if unused.

Warranty & Disclaimer

12-month warranty from shipment date.
Misuse voids warranty; follow specifications strictly.
