51.8V 30000mAh Drone Battery 300 Cycles 150A Peak Discharge

Brand Name : OiD

Model Number : OiDA988188-30000-5C-51.8

Certification : CE UL RoHS UN38.3

Place of Origin : China

MOQ : 100pcs

Price : $0.5 ~ $100.0 / pcs

Delivery Time : 3 ~ 7 days for storage

Payment Terms : TT,L/C,Western Union

Name : Drone Lithium Polymer Battery

Battery Type : 51.8V，30000mAh Rechargeable

ODM : Free custom design for packs

Cycle Life : 300+ cycles

Charging/ Discharging : 30A/90A

Operating Temperature : -20°C~60°C

Compatibility : AS150U-F (Discharge), Molex-430251600 (Balance)

Weight/ size : 5860g/208×89.5×152mm

Contact Now

OiDA988188-30000-5C-51.8 Drone Battery 51.8V 30000mAh 150A Peak Discharge 300 Cycles

Product Name

High-Performance 14S1P 51.8V 30000mAh Lithium Polymer Drone Battery

Advantages

Ultra-high voltage and capacity for heavy-duty drone applications
Optimized power-to-weight ratio for extended flight endurance
High-rate 5C discharge capability for demanding power requirements

Specifications

No.	Item	Specification
1	Configuration	14S1P (14 Series, 1 Parallel)
2	Nominal Voltage	51.8V (Cell: 3.7V)
3	Nominal Capacity	30000mAh @ 0.2C Discharge
4	Minimum Capacity	29300mAh @ 0.2C Discharge
5	Open-Circuit Voltage	58.8V (Cell: 4.2V)
6	Max Charge Current	30A (1C) to 58.8V, CV until ≤0.02C
7	Max Continuous Discharge	90A (3C) to 42.0V
8	Peak Discharge Current	150A (5C, ≤3s)
9	Internal Impedance	20±5.0mΩ
10	Dimensions (L×W×H)	208×89.5×152mm (Max)
11	Weight	5860±150g
12	Terminals	AS150U-F (Discharge), Molex-430251600 (Balance)

Cycle Life

Test Condition	Performance
1. Charge: 15A to 58.8V, end current ≤0.02C
2. Rest: 10min
3. Discharge: 90A to 42.0V	≥300 cycles (80% capacity retention)
4. Rest: 30min
5. Repeat steps 1–4 until capacity <80%

Discharge Curve

90A Discharge: ~18 minutes to 42.0V after standard charge.
Low-Temp Performance: ≥70% capacity at -20°C (0.2C discharge).

Operating Temperature Range

Scenario	Temperature Range	Current/Power Limit
Charging	10°C–45°C	≤30A (1C)
Discharging	-20°C–60°C	-20°C–0°C: ≤0.2C
		0°C–60°C: ≤90A (3C)
Storage (Short-term)	-20°C–35°C (≤7 days at >54.6V)	N/A
Storage (Long-term)	-20°C–35°C (52.5V–54.6V)	Activate every 3 months

Certifications

Complies with GB31241-2014/GB/T 18287-2013 safety standards.

Key Features

Fast Charging: Fully charges in 1.5 hours (30A) or 7.5 hours (6A).
High-Temp Stability: 95% capacity recovery after 60°C storage.
Low Self-Discharge: ≤15% capacity loss after 28 days at 23°C.

Applications

Heavy-lift industrial drones, long-endurance UAVs, and high-power aerial systems.

Usage Warnings & Precautions

Charging: Use CC/CV chargers (max 58.8V). Reverse polarity prohibited.
Discharging: Avoid >150A currents or temperatures <-20°C/＞60°C.
Physical Handling: Protect aluminum casing from sharp objects.

Storage Guidelines

Short-term: Store at 52.5V–54.6V (23°C).
Long-term: Maintain 52.5V–54.6V; activate every 3 months (0.2C cycle).

Warranty & Disclaimer

12-month warranty from shipment date. Void if misused (overcharge, puncture, etc.).
Not liable for accidents caused by improper operation.
